M-Series
Showing all 11 resultsSorted by price: low to high
-
$159.00Nominal length (mm)800Tube diameter (mm)76.10Weight (kg)4.20Item numberA0436 -
$192.00Nominal length (mm)1,000Tube diameter (mm)76.10Weight (kg)5.30Item numberA0434 -
$207.00Nominal length (mm)1,300Tube diameter (mm)76.10Weight (kg)7Item numberA0435 -
$267.00Nominal length (mm)1,300Tube diameter (mm)76.10Weight (kg)10Item numberA0443 -
$297.00Nominal length (mm)1,600Tube diameter (mm)76.10Weight (kg)12.50Item numberA0445 -
$327.00Nominal length (mm)2,100Tube diameter (mm)76.10Weight (kg)16Item numberA0447 -
$357.00Nominal length (mm)1,300Tube diameter (mm)88.90Weight (kg)11.50Item numberA0453 -
$411.00Nominal length (mm)1,600Tube diameter (mm)88.90Weight (kg)14Item numberA0454 -
$417.00Nominal length (mm)2,100Tube diameter (mm)88.90Weight (kg)18Item numberA0455 -
$477.00Nominal length (mm)1,600Tube diameter (mm)114.30Weight (kg)16Item numberA0419 -
$537.00Nominal length (mm)2,100Tube diameter (mm)114.30Weight (kg)21Item numberA0420
Each KRINNER ground screw has a structured product code that indicates its exact specifications:
- Series (KSF, KSF E, etc.) – Defines the screw type (Eccentric system, Flange, Thread fastening, Conical plastic, etc.).
- Shaft diameter (e.g., 140 mm) – The main body diameter of the screw.
- Nominal length (e.g., 1300 mm) – The total length of the screw.
- Further specification (e.g., E76, R, P, M) – Additional details such as adjustment diameter, flange type, torque, or thread design.
- Optional suffix (e.g., -100) – Number and size of lateral threads or other specific features.
This system ensures that each screw can be precisely identified and matched to its application, whether for foundations, extensions, or special constructions.
